Daylight shut-off. Selectable walk test. 300 W of halogen PAR38 lighting. Automatic power outage reset. Sensitivity adjustment. Wall or eave mountable. Patented swivel adjustment. Selectable light timer 1, 5 or 20 mins. Manual override. Operating temperature -22 to 120 deg F. Pulse count technology. Range boost doubles coverage area up to 13,000 sq-ft. Selectable range of 70 ft or 100 ft. Maximum coverage angle of 240 deg. Durable metal fixture. 2-level lighting. Off, 3 hrs, 6 hrs or dusk to dawn selectable timer. Protective metal lamp covers.
Product Details
Manufacturer: HEATHCO
Manufacturer's Part Number: HZ-5318-WH
Show me more Flood & Security Lighting
Product Features
- DualBrite® timer
- Automatically turns lighting Off
- Turns on lighting when motion is detected
- LED indicates motion was sensed (day or night)
- Photocell keeps the light off during daylight hours
Product Specifications
| Bulb Shape | PAR38 |
| Detection Range | 100 ft |
| Dimensions | 7.7 in W x 5.7 in D x 8.2 in H |
| Fixture Material | Metal/Plastic |
| Includes | (1) Gasket, (1) Light Control, (1) Mounting Strap, (1) Mounting Bolt, (1) Plastic Hanger, (1) Rubber Plug, (6) Screws, (2) Shells, (2) Wire Connectors |
| Lamp Base | Medium |
| Lamp Type | Halogen |
| Lamp Wattage | 150 W |
| Light Color | White |
| Mounting Type | Eave, Wall |
| Number of Lamps | 2 |
| Voltage Rating | 120 V |
| Wattage Rating | 300 W |
Product Documents
| Instruction/Installation Manual | Click here to download |
