SKU: 2476398
Brand: Cutler-Hammer
Senses hot wire-to-ground faults in a 4 to 6 mA range and shuts off the power. Applications include bathrooms, cellar outlets, swimming pools, outdoor branch circuits, garage and carport areas and kitchen branch circuits within 6 ft of the sink. Requires two 1 in spaces, common trip. UL listed, Meets UL 489. 120/240 VAC, 10,000 AIC.
Product Details
Manufacturer: EATON
Manufacturer's Part Number: GFCB230
Show me more Circuit Breakers
| Current Rating | 30 A |
| Dimensions | 6-1/2 in L x 6-3/4 in W x 7-1/4 in H |
| Interrupt Rating | 10, 22 kA |
| Mounting Type | Plug |
| Number of Phases | 1 |
| Number of Poles | 2 |
| Operating Frequency | 50/60 Hz |
| Suitable for | Ground Fault Interrupter |
| Trip Sensitivity | 5 mA |
| Trip Type | Common |
| Type | GFCI, Type GFCB |
| Voltage Rating | 120/240 V |
| Wire Size | 14 to 4 AWG |
| Catalog | Click here to download |
| Specification Sheet | Click here to download |
