    Home / FORNEY INDUSTRIES / Forney 314 Arc Welder, 230 V Input, 235 A, 1-Phase, 24 ga to 1/2 in Thick, 50 % Duty Cycle
    Forney 314 Arc Welder, 230 V Input, 235 A, 1-Phase, 24 ga to 1/2 in Thick, 50 % Duty Cycle
    Forney 314 Arc Welder, 230 V Input, 235 A, 1-Phase, 24 ga to 1/2 in Thick, 50 % Duty Cycle
    Forney 314 Arc Welder, 230 V Input, 235 A, 1-Phase, 24 ga to 1/2 in Thick, 50 % Duty Cycle
    Forney 314 Arc Welder, 230 V Input, 235 A, 1-Phase, 24 ga to 1/2 in Thick, 50 % Duty Cycle
    Forney 314 Arc Welder, 230 V Input, 235 A, 1-Phase, 24 ga to 1/2 in Thick, 50 % Duty Cycle
    Forney 314 Arc Welder, 230 V Input, 235 A, 1-Phase, 24 ga to 1/2 in Thick, 50 % Duty Cycle
    Forney 314 Arc Welder, 230 V Input, 235 A, 1-Phase, 24 ga to 1/2 in Thick, 50 % Duty Cycle
    Forney 314 Arc Welder, 230 V Input, 235 A, 1-Phase, 24 ga to 1/2 in Thick, 50 % Duty Cycle
    Forney 314 Arc Welder, 230 V Input, 235 A, 1-Phase, 24 ga to 1/2 in Thick, 50 % Duty Cycle
    Forney 314 Arc Welder, 230 V Input, 235 A, 1-Phase, 24 ga to 1/2 in Thick, 50 % Duty Cycle

    Forney 314 Arc Welder, 230 V Input, 235 A, 1-Phase, 24 ga to 1/2 in Thick, 50 % Duty Cycle

    SKU: 8909400

    Brand: Forney

    $1,149.99$0.00
    2 items left


    In stock for FREE pickup in Whitinsville
    Check Nearby Stores

    This welder has a duty cycle of 20% at 230 A, 50% at 150 A AC, 20% at 180 A and 35% at 135 A DC. The electroholder cable is 3 m 25 sq-mm, the earth clamp cable is 2 m 25 sq-mm, both with dense connector. Input cable American wire gauge (AWG) 10, 2.5 mm. 50 A plug. CSA certified Cat #00329, wheel and handle kit for "Forney" 00313 and 00314 must be purchased separately. Weighs 116 lb (52.62 kg).

    Product Details

    Manufacturer: FORNEY INDUSTRIES

    Manufacturer's Part Number: 314

    Show me more Arc Welders

    • Larger work envelope
    • Illuminated On/Off switch and fan cooling system
    • AC/DC CC welding from 24 ga to 1/2 in thickness at 45 to 235 A
    • Ready to weld right out of the box, only handle assembly required
    • Dinse style connection provides easy polarity change and cable repairs
    Cable Length 15 ft
    Dimensions 12 x 16-1/2 x 30-1/2 in
    Duty Cycle 50 %
    Frequency Rating 60 Hz
    Includes 15 ft Ground Cable and Clamp, 15 ft Power Cord, 15 ft Welding Cable and Electrode Holder
    Input Voltage 230 V
    Number of Phases 1
    Rated Output 235 A
    Weight 108 lb
    Welded Range 24 ga to 1/2 in Thick
    Owners/User Manual Click here to download
    Specification Sheet Click here to download
