The ultimate in controlling light, ASPIRE smart dimmer accessory are compatible with master dimmers for multi-location access. Each dimmer features advanced modes of operation like rapid and delayed fading, LED light-level display for presetting illumination levels and master with accessory units for multi-point control.
Product Details
Manufacturer: EATON
Manufacturer's Part Number: 9542WS
Show me more Dimmers
Product Features
- Power failure memory
- Switch has quiet, smooth actuation
- Electrostatic discharge protection
- Neutral is not required for installation of device
- Durable top and backbody for long reliable performance
- Replaces a standard switch and offers dimming capabilities
- Radio frequency interface filtering is standard on all models
- Incandescent/halogen and magnetic low-voltage offered in single unit versions
Product Specifications
| Color | White |
| Control Type | ON/OFF Push Pad |
| Dimensions | 2.45 in L x 1.38 in W x 3.81 in H |
| Frequency Rating | 60 Hz |
| Lamp Type | CFL, Halogen, LED |
| Material | Polycarbonate |
| Mounting Type | Flush |
| Number of Phases | 1 |
| Number of Poles | 1 |
| Operation Modes | 3-Way |
| Start Type | Rapid, Preset |
| Temperature Rating | 0 to 40 deg C |
| Terminal Type | Lead Wire |
| Voltage Rating | 120 V |
| Wattage Rating | 600 W |
Product Documents
| Catalog | Click here to download |
