GATES MegaCrimp G25175-0608 Hose Coupling, 3/4-16, Crimp x JIC, 45 deg Angle, Steel, Zinc

GATES MegaCrimp G25175-0608 Hose Coupling, 3/4-16, Crimp x JIC, 45 deg Angle, Steel, Zinc

SKU: 3536679

Brand: GATES

Regular price
Sale price
Regular price
Sold out
Unit price
In stock for FREE pickup in Whitinsville

MegaCrimp® couplings give you a leak-proof seal that's so innovative, it's patented. It's what's inside the MegaCrimp® coupling that makes it perform so well, the "C" insert. This "C" insert allows usage with different constructions and wall thicknesses. In addition, the "C" insert ensures an even distribution of crimping forces to form a concentric seal. That simplifies your inventory requirements since one size can accommodate many different hose ODs, on both one and 2-wire hoses. MegaCrimp® couplings are a fully-qualified EN-performance coupling.

Product Details

Manufacturer: GATES

Manufacturer's Part Number: G25175-0608

Show me more Hydraulic Hose Fittings

Product Features

  • TuffCoat plating
  • Crimps on all wire braid hose
  • Fully integrated with gates MegaSys hose
  • Less sensitive to material and processing flaws
  • Large holding shoulder evenly distributes stress forces
  • Surpassed one million impulse cycles during design testing
  • MegaCrimp couplings set a new standard for hydraulic couplings
  • Higher resistance against cracking, even when inadvertently over-torqued
  • More consistent transfer of input-torque to clamp-load results in fewer leaks
  • The unique "C" insert ensures "weep-free" concentric crimping to keep equipment and the environment clean
  • One of the most common causes of hydraulic leaks is a cracked coupling nut or seat due to over-torqueing by a strong-armed worker

Product Specifications

Angle 45 deg
Connection Type Crimp x JIC
Cut-Off Length 2.41 in
Diameter 3/8 x 3/4 in
Finish Zinc
Hex Size 24 mm
Length 3-1/2 in
Material Steel
Nominal Size 3/4-16
Suitable for CM2T, G1, G1H, G2, G2H, G2L, G2XH, G3H, G4H, GMV, GTH, GTHX, J2AT, M-XP, M2T, M3K, M3KH, M4 Series Hose
Wall Thickness 0.59 in
